Our resins are qualified on industry leading DLP Printers


NEXA NXE400

DLP Printer

With an unprecedented 16L build volume, intelligent optimization, and Nexa3D’s revolutionary patented LSPc technology, the NXE 400 is the perfect printer for any application.

  • Print Tech: Continuous LSPc
  • Light Source: Structured Light Matrix
  • XY Scanning: 75 μm
  • Build Area: 280x165x400 mm (11×6.5×15.74 inch)
  • Z Resolution: 50/100/200 microns
  • Z Coordinate: Z-Axis and Vat
Genera

Downloads:

pdf-icon-symbol-5

G2

DLP Printer

Output increases, while printing costs stay low. While the handling of printed components of conventional 3D printers is often arduous and unclean, the G2 offers a glove-free workflow for clean, easy, and reliable production. The G2 prints in 4K and several different resolutions (between 40 and 100 μm) in one system. No matter what the needed printing accuracy is, G2 has the solution, in one system.

  • Light intensity: max. 20 mW / cm2
  • Wave length: 385 nm DLP
  • Speed: Up to 3 mm / min*
  • 4K Resolution (3840 x 2160)
  • Pixel size: 100 μm, 70 μm, 40 μm
  • Print volume: x: 384 mm, y: 216 mm, z: 350 mm

Downloads:

pdf-icon-symbol-5

Origin One

DLP Printer

  • Origin has validated a wide range of photopolymers from LOCTITE including silicone elastomers, flame retardant polymers, molding materials and general engineering purpose materials.
  • A manufacturing-grade printer that enables additive mass production of end-use isotropic parts.

  • Build Size: 192mm x 108mm x 350mm

  • Footprint: 400mm x 450mm x 1100mm

  • Exceptional Accuracy, Consistency, and Throughput
  • Produce features as small as 50µm
  • Print molds with large cross sectional areas
EnvisionOne Picture

Downloads:

pdf-icon-symbol-5

Envisiontec E1

cDLM Printer (DLP)

  • 385 nm UV LED
  • X,Y Resolution: 93 µm
  • Z Resolution1: 50 μm to 150 μm
  • Build Envelope: 180 x 101 x 175 mm
  • Build Speed: Up to 45 mm/hour (material dependent
  • Layerless technology delivers smooth models
  • 75% less supports compared to regular
  • DLP Domeless technology delivers high accuracy in Z
  • Closed system (RFID)

1material dependent


NewPro NP1

DLP Printer

  • 405 nm UV LED
  • X,Y Resolution: 75 µm
  • Z Resolution: 50 – 100 µm
  • Build Envelope: 192x 120 x 300 mm
  • The Intelligent Liquid Interface (TM) is a membrane that speeds up the print process while reducing the suction forces traditionally acting on the print object as it prints.
  • Broad material compatibility
  • High print speeds (human skull in one hour)
  • Long membrane life
  • Ability to heat up the chamber for high viscosity resins
  • Minimal support structures
  • Fast post processing.

Downloads:

pdf-icon-symbol-5

Rapidshape I30+

DLP Printer

  • 385 nm UV LED
  • X,Y Resolution: 78 µm
  • Z Resolution1: 25-200 µm
  • Build Envelope: 150 x 85 x 120 mm
  • Build speed: Up to 80 mm/hour
  • Patented Force Feedback system to monitor separation forces
  • Flexible open system facilities manual adjustment and control
  • Open System / closed upon request (RFID)
  • Simple operation for professional and validated use

1material dependent


Downloads:

pdf-icon-symbol-5
Fortify logo red _Vertical

Flux One

DLP Printer

Fortify’s FLUX ONE printer brings the next level of performance to additive manufacturing with its proprietary CKM (Continuous Kinetic Mixing) and Fluxprint magnetic alignment technologies.

  • Build volume: 8 in (x) x 4.5 in (y) x 13 in (z) / 203.7 mm x 114.6 mm x330 mm
  • Z (layer height) resolution: 10 – 250 µm
  • XY (pixel pitch) resolution : 75 µm
  • CKM features an onboard mixer that keeps fiber and other functional additives in uniform suspension throughout a part.
  • Fluxprint magnetic alignment uses a magnetic field to align fibers in a resin matrix. This unique ability to control fiber orientation throughout a part is unprecedented in any manufacturing technology.
  • Applications: Mold tools with high cross sections and end use parts that require enhanced mechanical performance (strength, stiffness, toughness, wear, and heat deflection temperature) as well as thermal and electrical properties.

Asiga MAX UV

DLP Printer

  • 385nm or 405nm LED
  • XY Resolution: 62µm
  • Z Resolution: From 1µm
  • Build Speed: Up to 60mm/hr
  • SPS™ technology monitors layer formation for accurate and repeatable results.
  • 100% Open Material System
  • Single point calibration
  • Fast material change – under 30 seconds (no calibration required)
  • Unlimited Lifetime Technical Support included

Asiga Pro 4K

DLP Printer

  • 365nm, 385nm or 405nm LED
  • XY Resolution: 46µm
  • Z Resolution: From 1µm
  • Build Speed: Up to 60mm/hr
  • SPS™ technology monitors layer formation for accurate and repeatable results.
  • 100% Open Material System
  • Single point calibration
  • Fast material change – under 30 seconds (no calibration required)
  • Unlimited Lifetime Technical Support included
